UWBSpekChek™ WiMedia Platform Compliance
Test Guide
rev3.10 2 Page 33 of 33
the scheduled BPST (from 0 +/- 4us). After 30 seconds power is removed from DUT &
INTD device and trace is reviewed verify proper beacon behavior.
Test procedure:
1. Start analyzer capture with filter set to only capture beacon frames.
2. Start test system transmitting beacons in slots 2–10 with nominal intervals of 65538
microseconds (as reported by the analyzer). Each beacon is sent a random number
of microseconds from 0 to 4 earlier than the scheduled location based on the
nominal interval. The BP Length is set to 21. The EUI-48 in all the test system
beacons is set to NULL and the DevAddr is set to 2.
3. Standard test start-up sequence.
4. After 30 seconds, the DUT and INTD are shut down by using a power control on the
device or by unplugging the power cable (if no control is present).
5. After 1 minute, test system stops beaconing.
6. Stop the analyzer capture.
Notes:
• Background observation checks verify DUT & INTD follow correct beacon group
join behavior.
• If the DUT or INTD are connected to a PC the test is repeated with PC placed
into standby or hibernation during step 4.
Non-Automated Test Cases:
The test cases listed below currently are not performed by UWBSpekChek:
• Test Case 1.6:
This test case should be performed manually. Refer to the comments in
the generation script to do it step by step
• Test Case 3.7:
This test case should be performed manually. Use corresponding
generation script and proper buffer size from recording option to perform
test.
• Test case 5.1
There is no test system stimulus defined for this test.
