2. Test system starts the beacon period and sends a beacon in slot 2 with a DRP IE
that reserves the first row and low row in the superframe with reservation type
Hard DRP. The BP Length is set to 12.
3. Standard test start-up sequence.
4. The test system stops sending beacons.
5. After at least 2 seconds, stop analyzer capture.
Notes:
In addition to passing the normal background checks, the DUT/INTD should detect the
existing reservation and establish its own reservation in non-conflicting MAS.
Test Case 3.1: TD.8.2.3.2 Beacon Join With BP Length Expansion
This test verifies that the DUT sets the BP length correctly and extends the length when
the tester relocates to a higher slot. The tester begins beaconing in slot 9 with movable
bit set. The DUT and INTD should join in a higher slot and set movable and contract to
the lowest available slots.
Test procedure
1. Start analyzer capture.
2. Test system starts the beacon period and sends a beacon in slot 9 with the
movable bit not set and with a BP Length of 10.
3. Standard test start-up sequence.
4. After DUT and INTD join the test system expands its BP Length.
5. After 1 second, test system stops beaconing.
6. After at least 2 seconds, stop analyzer capture.
Notes:
• Background observation checks verify DUT & INTD follow correct signaling and
slot contraction behavior
• It is allowable that the first DUT beacon can be marked movable without waiting
4 superframes (this is not required behavior). Both DUT and INTD must be
marked movable by the 5th superframe after joining.
