30
ISSUED: November 2001 PXD222-OM-E Rev A
PXD 222 Digitizer
PHYSICAL DIMENSIONS
Height.........................................3 U (13.3 cm, 5.25 in.)
Width ..........................................2 slots (3.9 cm, 1.56 in.)
Weight ........................................0.77 kg (1.7 lb.)
POWER REQUIREMENTS
Input voltage at cPCI connector ....... 5 V ±10%
Input current..................................... 1.6 A
ENVIRONMENTAL CONDITIONS
Temperature
Operating ...................................0 °C to 50 °C (32 °F to 122 °F) with specified cooling of PXI
rack (indoor use only)
Non-Operating ...........................–40 °C to +71 °C
Humidity
Operating ...................................5% to 95% max. RH (non-condensing) up to 30 °C; upper
limit derates to 45% RH (non-condensing) at 40 °C (104 °F)
Non-operating ............................5% to 95% max. RH (non-condensing) up to 30 °C; upper
limit derates to 45% RH (non-condensing) at 60 °C (140 °F)
Altitude
Operating ...................................4600 m (15,092 ft.)
Non-operating ............................12,000 m (39,377 ft.)
Altitude
Conforms to MIL-PRF-28800 Class 3
