28
ISSUED: November 2001 PXD222-OM-E Rev A
PXD 222 Digitizer
40 ns to 2.4 s/S ..........................20 MS/s
4.8 s/S ........................................4 MS/s
(See the chapter on Operation for more information.)
Acquisition Modes: Real Time, Single Sweep
Normal Acquisition Mode:
Record size ................................up to 1000 samples/ch
Record time span .......................100 ns to 10 s
Glitch Capture Mode:
Record size ................................250 points (Min. and Max data arrays returned)
Recorded time span ...................50 µs to 10 s; detects glitches as fast as 50 ns by
oversampling waveform
Sample rate................................up to 2.5 GS/s
Scope Record Size:
Record size ................................27 points (Min. and Max data arrays returned)
Sample rate................................up to 20 MS/s
TRIGGER
Trigger Modes: Automatic, Edge, Video, Pulse Width
Trigger Delay: up to +25000 samples
Pre Trigger View: 2500 samples
Max. Delay: 10 s
Edge Trigger:
Mode ..........................................On Trigger, Single Shot
Source........................................Ch1, Ch2, PXI_TRIG[0,1,2…7],PXI_STAR[0,1,2…7]
Slope ..........................................Positive, Negative
Trigger Level Control Range:
Input Ch1, Ch2 ...........................100% of full range
PXI_TRIG[0,1,2…7] ...................fixed C-mos Cpci-level
PXI_STAR[0,1,2…7] ..................fixed C-mos Cpci-level
