Specifications
PXD222-OM-E Rev A ISSUED: November 2001
27
ASpecifications
PXD 222 DIGITIZER SPECIFICATIONS
VERTICAL SYSTEM
Bandwidth (DC coupled): 200 MHz (–3dB)
Lower Frequency Limit (AC coupled):
with 10:1 probe........................... < 2 Hz (–3dB)
direct (1:1) .................................. < 5 Hz (–3dB)
Rise Time: 1.7 ns
Analog Bandwidth Limiters: 20 MHz and 10 kHz
Input Coupling: AC, DC
Full Scale ranges:
direct (1-2-5 sequence) .............. 40 mV to 800 V
with 10:1 probe........................... 400 mV to 8000 V
Positioning (% of full range): 100%
Input Impedance on BNC:
DC Coupled................................1 M
?
ohms (±1%) // 15 pF (±2 pF)
Max. Input Voltage
with 10:1 probe........................... 1000 V CAT II
direct (1:1) .................................. 300 V CAT II
(For detailed specifications, see “SAFETY”)
Vertical Accuracy: ±2% of full range
Digitizer Resolution: 8 bits, separate digitizer
HORIZONTAL SYSTEM
Maximum Time Base Speed: 400 ps/sample
Minimum Time Base Speed: 4.8 s/sample (scope record mode)
Real Time Sampling Rate (for both inputs simultaneously):
400 ps to 80 ns/S ....................... up to 2.5 GS/s
NOTE: Specifications are subject to
change without notice.
