Operation
PXD222-OM-E Rev A ISSUED: November 2001
19
Table 2: Glitch Capture Mode Time Windows, Intervals, and Sample Rates
Time Window Sampling Time
Interval for Each
Point
Real Time
Sampling Rate a
a. Waveform is oversampled at the real time sampling rate. Within
each time interval, the minimum and maximum values are
stored. A total of roughly 27 kpts are stored in the MIN and MAX
arrays.
100 ns 400 ps 2.5 GS/s
200 ns 800 ps 2.5 GS/s
500 ns 2 ns 2.5 GS/s
1 µs 4 ns 2 GS/s
2 µs 8 ns 1 GS/s
5 µs 20 ns 200 MS/s
10 µs 40 ns 100 MS/s
20 µs 80 ns 50 MS/s
50 µs 200 ns 20 MS/s
100 µs 400 ns 20 MS/s
200 µs 800 ns 20 MS/s
500 µs 2 µs 20 MS/s
1 ms 4 µs 20 MS/s
2 ms 8 µs 20 MS/s
5 ms 20 µs 20 MS/s
10 ms 40 µs 20 MS/s
20 ms 80 µs 20 MS/s
50 ms 200 µs 20 MS/s
100 ms 400 µs 20 MS/s
200 ms 800 µs 20 MS/s
500 ms 2 ms 20 MS/s
1 s 4 ms 20 MS/s
2 s 8 ms 20 MS/s
5 s 20 ms 20 MS/s
10 s 40 ms 20 MS/s
