ALUMINUM VIEWPOINT RUNNING BOARDS
2014 SORENTO
Page 6 of 8 12/4/13 Rev1 (DP)
Passenger Side Installation Pictured
(Fig 10A) Insert Spacer between
the Bracket and the body panel
12mm Lock Washer
12mm Flat Washer
12mm Hex Nut
Fig 10B
Rear
Insert Spacer between the Bracket and the body panel
Fig 11
Spacer
Rear
Fig 12
Slide the correct Rubber Strip into channel
on back of Running Board. Installation of 2"
tall backing for LX & EX pictured for example
(Fig 13) Slide (3) 6mm T-Bolts into each
channel on bottom of Running Board
Front
12mm x 40mm Short
Low Profile Bolt Plate
