Page 58 of 58 FIRElink-400 Air Sampling System – Installation Manual
© 2010 Hochiki Europe (UK) Ltd 9-5-0-346/ISS4/OCT10
15 FIRElink-400 Specification
SELV Rating (EN 60950) Class III
Supply Voltage
21.6Vd.c. - 26.4Vd.c.
PSU Type: conforming to EN 54-4
Electrical safety complies with IEC 61010-1
Size (mm) 427W x 372H x 95D
FIRElink-400 5.2
FIRElink-400CM 5.3
FIRElink-CM 6.2
Weight (kg)
FIRElink-CM with batteries 10.1
Operating Temperature Range
0 to +38°C (UL268 compliance)
-10 to +60°C (CEA 4022 compliance)
Operating Humidity Range
0 - 90% Non Condensing
IEC 61010-1 Pollution degree 1
IEC 61010-1 Installation Cat. II
0.03% to 25% Full Scale Deflection (FSD)
Measurement Range (obs/m)
0.0015% to 25% Sensitivity Resolution
Detection Principle Laser light scattering mass detection
Particle Sensitivity Range 0.0003µm to 10µm
FIRElink-400 470 (fan speed 8)
FIRElink-400CM 920 (fan speed 8) Current Consumption (mA)
FIRElink-CM 450
Relay Contact Rating 500mA @ 30Vd.c.
Maximum Sampling Pipe Length 200 metres @ 100 sampling holes
Sampling Pipe Inlets 4
Sampling Pipe Internal Diameter 15-25mm
Alarm levels 4 – (FIRE 2, FIRE 1, PREALARM and AUX)
Bargraph Sensitivity Range 0.0015 – 25% Obs/m
Bargraph Segments 26
Chamber Service Intervals Greater than 8 years (depending on environment)
Dust Separator Replacement Intervals Greater than 5 years (depending on environment)
Laser Lifetime (MTTF) Greater than 1000 years
Programming Front Panel or PC via RS232/RS485
Data Bus Cable RS485 data cable
Data Bus Length 1.2 km IN, 1.2km OUT
IP Rating IP50
Supported Languages on Internal Programmer
Czech, Dutch, English, Estonian, Finnish, French,
German, Hungarian, Italian, Norwegian, Spanish,
Swedish
NOTE: This equipment is only to be used in accordance with this specification. Failure to operate the
equipment as specified may cause damage to the unit.
