The following shows a BR-MultiBrick32 information status re-
sponse for a card which is operating as a 'Dumb' Brick:
Gilderfluke & Co. MultiBrick32
firmware revision 2.10
copyright 2002 DCM
Card addressed at 00h/__0
4 Mbits (512KBytes) memory installed
Writing to Flash is Enabled
Input A/Green now Open
Input B/Red now Open
Input C/Blue now Open
Input D/White now Open
Dumb Brick show 01h/__1 KOKIMO looping @ frame 00F27h/___3879
AutoDownload FileName: TEST.A00
Number of channels: 04h/__4
Number of shows: 06h/__6
00 B0 A1 01 04 06 01 01 08 00 01 00 04 00 01 00 08 01 01 00 20 04 40 00
01h/__1 st:00000h/______0 len:0122Ah/___4650 fl:EDh nxt:01h/__1 KOKIMO.SHO
02h/__2 st:0122Ah/___4650 len:01374h/___4980 fl:CDh nxt:00h/__0 MARGVILL.SHO
03h/__3 st:0259Eh/___9630 len:01248h/___4680 fl:CDh nxt:00h/__0 CHEEBURG.SHO
04h/__4 st:037E6h/__14310 len:0122Ah/___4650 fl:CDh nxt:00h/__0 FRUTCAKE.SHO
05h/__5 st:04A10h/__18960 len:00EA6h/___3750 fl:CDh nxt:00h/__0 IGETARND.SHO
06h/__6 st:058B6h/__22710 len:00F96h/___3990 fl:CDh nxt:00h/__0 409.SHO
(Sample data: Your show data will differ from what is shown.)
“j5AA5” [nn] (card address) Card Reset:
This command will erase the 'Flash' memory on the BR-
MultiBrick32. The BR-MultiBrick32 will also determine the type and
quantity of memory chips installed and report this and the soft-
ware revision number when it accepts this command.
Start Commands:
“t” [nn] (card address) Start Track:
“u” Start Global:
These commands are available ONLY on 2.0 or later revision
cards which are being operated as ‘Dumb’ Bricks. If your system
has a 'Smart' Brick Brain, then these commands should be ad-
dressed to the 'Brain'.
These commands start the animation playing on the BR-
MultiBrick32(s) addressed by the command. The shows will always
start from the beginning. If an addressed BR-MultiBrick32 is looping
shows, it will have the ‘LOOPING SHOWS’ flag reset.
If the BR-MultiBrick32 receives a start command after it has re-
ceived a request for a specific show, it will play that show. Other-
