Edge Connector: All of the connections to and from BR-MultiBrick32
Cards are available on the 60 position edge connector. You can
use an Insulation Displacement Edge (IDE) connector if you aren’t
going to be using one of our card cages:
output wire # Edge pin #color wire function
J8 Black (common) 1 brown J8 Common (black)/'Smart' Brick Net Data-
J8 White (Reset) 2 red J8 ‘D’ (white) input/'Smart' Brick Net Data +
J8 Red (Stop) 3 orange J8 ‘B’ (red) input/'Smart' Brick Net Clk +
Serial Port red #3 4 yellow TxD + out from BR-MultiBrick32
J8 Green (Start) 5 green J8 ‘A’ (green) input/'Smart' Brick Net Clk -
Serial Port Black #2 6 blue TxD - out from BR-MultiBrick32
J8 Yellow (Status Out) 7 violet J8 Status (yellow) out/'Smart' Brick Strobe +
Serial Port Yellow #5 8 gray Rx + in to BR-MultiBrick32
J8 Blue (Clock/Dbl. Show) 9 white J8 ‘C’ (blue) input/'Smart' Brick Net Strobe -
Serial Port green #4 10 black Rx -in to BR-MultiBrick32
#1 11 brown J6 out channel 0 Ground
#2 12 red J6 out channel 0 bit 7
#3 13 orange J6 out channel 0 bit 6
#4 14 yellow J6 out channel 0 bit 5
#5 15 green J6 out channel 0 bit 4
#6 16 blue J6 out channel 0 bit 3
#7 17 violet J6 out channel 0 bit 2
#8 18 gray J6 out channel 0 bit 1
#9 19 white J6 out channel 0 bit 0
#10 20 black J6 out channel 0 + Supply
#11 21 brown J6 out channel 1 Ground
#12 22 red J6 out channel 1 bit 7
#13 23 orange J6 out channel 1 bit 6
#14 24 yellow J6 out channel 1 bit 5
#15 25 green J6 out channel 1 bit 4
#16 26 blue J6 out channel 1 bit 3
#17 27 violet J6 out channel 1 bit 2
#18 28 gray J6 out channel 1 bit 1
#19 29 white J6 out channel 1 bit 0
#20 30 black J6 out channel 1 + Supply
#21 31 brown J6 out channel 2 Ground
#22 32 red J6 out channel 2 bit 7
#23 33 orange J6 out channel 2 bit 6
#24 34 yellow J6 out channel 2 bit 5
