Salamander Designs FX100/S User Manual
Page 10
ENG
ESP
FRA
Install Mount Assembly
10
Faire glisser le support de téléviseur (II) sur le support mural
(I) par le haut.
3. Install TV to Wall Bracket
Locate side hole in Wall Bracket (I) and secure
with Lock (IV).
3
. Install TV to Wall Bracket
Slide TV Bracket (II) into Wall Bracket (I) from top.
A
B
Deslice el Soporte de TV (II) en el Soporte de Pared (I)
desde arriba.
Localice el agujero lateral en el Soporte de Pared (I)
y fíjelo con el Candado (IV).
Repérer l’orifice latéral sur le support mural (I) et sécuriser
avec un verrou (IV).
