1. INTRODUCTION
The SlimZone Classic (2701-001/2701-006) zone panel is designed to control conditioned
air in separate zones using a single heating and cooling unit. Model 2701-001 controls up
to 3 zones; model 2701-006 controls up to 2 zones. SlimZone is compatible with both
single stage heating and cooling units and single compressor heat pumps with auxiliary
heat. The temperature of each zone is controlled by its own individual thermostat and duct
mounted motorized damper assemblies which control the distribution of conditioned air
into each zone. All zone thermostats and dampers are wired directly to the SlimZone
Classic control panel. The control panel is wired to the HVAC equipment. Power to the zone
thermostats and motorized dampers is provided by the control panel. A dedicated 24VAC,
75 VA transformer is required to power the control panel.
1.1.
IMPORTANT NOTE
IT IS IMPORTANT THAT YOU READ AND UNDERSTAND THIS MANUAL SUPPLIED WITH
THE SLIMZONE
CLASSIC , AS WELL AS THE HVAC EQUIPMENT MANUFACTURER’S INFOR-
MATION, BEFORE INSTALLING THE SYSTEM.
1.2. FEATURES
• Ultra slim styled cabinet [8 3 /
4
" (22.5cm) W x 9 1 /
2
" (24cm) H x1 3 /
4
" (4.5cm) D]
• First call priority method of operation
• Uses conventional 2 to 5 wire thermostats
• LED (light emitting diode) indicators on all system functions
• Solid state logic panel with current limiting outputs
• Controls heat pumps, cooling units, and gas, oil or electric furnace units
• Model 2701-001 controls up to 3 zones. Model 2701-006 controls up to 2 zones
• Controls 1 stage of heating and 1 stage of cooling in heat/cool applications or
1 compressor with auxiliary heat in heat pump applications
• 15 minutes to upstage to auxiliary heat on heat pumps
• 2 or 3 wire damper actuator capability
• All low voltage wiring
• Minimum on/off times of 4 minutes (short cycle protection)
• Minimum on/off time override switch
• Remote mode selector switch capability
• 45 second fan purge into last zone(s) calling
• Slide switch selector to set:
Heat pump or heat/cool
Add-on or normal
Plenum fan control or fan with heat call
Emergency heat
1.3. SAFETY INSTRUCTIONS
• Sudden operation may cause serious injury from moving parts. Leave power disconnected
until installation is complete.
• Sharp edges may cause damage to wires. Use care during the installation.
• Installation must be done in accordance with all local applicable codes and regulations.
• Installer should touch a grounded metal object before handling the SlimZone Classic com-
ponents and thermostats to avoid potential loss of internal computer programs due to
static discharge.
SlimZone Classic 1
