11. GLOSSARY
Auxiliary/Emergency
Applies to heat pump applications only. If the call for heat is not satisfied
Heat
within 15 minutes, auxiliary heat is energized and will remain on until the
call is satisfied. In the event of a heat pump compressor failure,
emergency heat (EH) is activated through an EH switch located on the
control panel.
Bypass System
A bypass system maintains uniform static pressure in the system ductwork
by modulating a motorized bypass damper in the main supply duct.
Mode of Operation
A mode is a specific operating setting (Off, Cool, Heat, Auto, E Heat)
which can be established at the control panel and the zone thermostats.
Zone
A defined area that is controlled by a zone thermostat and motorized
zone damper. Zone thermostats request heating or cooling from the SZC
control panel, which in turn controls the HVAC equipment and zone
dampers accordingly.
