20
Item Qty Description
SP11 SP15
Pump Material Pump Material
PP PVDF PP PVDF
8 1
Impeller Drive Assembly
6-Pole with carbon bushing 105913 105913-3 105913 105913-3
8-Pole with carbon bushing 105913-1 105913-4 105913-1 105913-4
10-Pole with carbon bushing 105913-2 105913-5 105913-2 105913-5
6-Pole with PTFE bushing 105913-6 105913-9 105913-6 105913-9
8-Pole with PTFE bushing 105913-7 105913-10 105913-7 105913-10
10-Pole with PTFE bushing 105913-8 105913-11 105913-8 105913-11
6-Pole with alumina ceramic bushing 105913-12 105913-15 105913-12 105913-15
8-Pole with alumina ceramic bushing 105913-13 105913-16 105913-13 105913-16
10-Pole with alumina ceramic bushing 105913-14 105913-17 105913-14 105913-17
6-Pole with silicon carbide bushing 105913-18 105913-21 105913-18 105913-21
8-Pole with silicon carbide bushing 105913-19 105913-22 105913-19 105913-22
10-Pole with silicon carbide bushing 105913-20 105913-23 105913-20 105913-23
8A 1
Impeller Bushing Only
Carbon J100977
Filled PTFE 106386
Alumina ceramic 106386-2
Silicon carbide 106386-1
9 1
Impeller Shaft
Alumina ceramic 105811-1
Silicon carbide 105811-2
Hastelloy C 105811-3
10 1
O-Ring
EPDM 105717
FKM 105716
11 1
Barrier
105689-3 105689-4 105689-3 105689-4
12 1
Motor Adapter
Standard motor adapter - all frame sizes 107405 107406 107405 107406
Standard motor adapter with non-sparking ring - all frame sizes 107407 107408 107407 107408
Note: 182/184TC & all IEC frames MAY need to order motor adapter flange (item 14) and hardware (items 22-24 & 25-27)
12A 1
Barrier/Clamp Ring O-ring
Buna 107281
FKM 107279
EPDM 107280
12B 1
Clamp Ring
Painted cast iron (Standard) 107228 107228-1 107228 107228-1
Painted cast iron with non-sparking ring 107322 107322-1 107322 107322-1
Stainless steel 108600 108600 108600 108600
Stainless steel with non-sparking ring 108600-1 108600-1 108600-1 108600-1
12C 1
Clamp Ring/Motor Adapter Column O-ring
Buna 107282
FKM 107283
EPDM 107284
12D 1
Motor Adapter Column
Standard 106890 106890-1 106890 106890-1
SP11/15 Spare Parts List - cont.
