Section 5: Parts
04/10 34 51205 Rev. 2
6.2. PARTS LIST
Part No. Description Location Qty
107171 BASE PLT WLDMENT Rests on foundation surface 4
86355 ROUND,THD,RH, 3/4 X 9 1/2" Drill-in-place all-thread anchor 20
108877 ADHESIVE LOCTITE FIXMASTER Epoxy tube for drill-in-place anchor bolts 20
108878 ADHESIVE APP GUN DISPENSER Caulk-type gun for epoxy tubes 1
61744 CLAMP PLATE FOR BASE PLATE Clamp plate for base plates 8
54233 3/4" FLAT WASHER Flat washers for anchors 20
54264 3/4-10 HEX NUT Hex nuts for anchors 20
54474 3/4-16 X 4 HEX BOLT GR 8 FINE Secure top receiver plate to platform 16
54776 3/4" SPRING LOCK WASHER, ZINC
Used with part 54474 for top receiver
plate
17
108120 FTEC 3 1/2" ROCKER 15K 15' CBL For 30k capacity scales 4
108121 FTEC 3 1/2" ROCKER 30K 15' CBL For 50k capacity scales 4
83669 FTEC 3 1/2" ROCKER 50K 15' CBL For 80k capacity scales 4
105718 2.5" UPPER CUP W/O ANTI ROTATE Inserts into top receiver plate 4
144201
LOAD LEVELLING SHIM 2 1/8 OD .010
TH Place between upper cup and top
receiver plate.
8
144202 LOAD LEVELLING 2 1/8 OD .031 TH
Place between upper cup and top
receiver plate.
8
144203 LOAD LEVELLING 2 1/8 OD .062 TH
Place between upper cup and top
receiver plate.
4
86337 TOP REC PLT,2"X6"X9 3/4" LG Bolts to platform 4
107174 SPACER PLT,1/2"X5 1/2"X9 3/4"
Between upper receiver plate and
platform
4
144205 SHIM, 1/8" PLATFORM SHIM
Between upper receiver plate and
platform
8
144206 SHIM, 3/16" PLATFORM SHIM
Between upper receiver plate and
platform
4
144204 LOCATING TOOL, 3 1/2" Load cell dummy 4
86326 CHECK BRKT WLDMNT, LH Check bracket for one corner 2
86325 CHECK BRKT WLDMNT, RH Check bracket for one corner 2
86357 1-8 X 4" FULL THD BOLT Lateral and longitudinal check bolt 8
54277 1-8 HEX NUT, ZINC Nuts to secure check bolts 16
12838 CABLE ASSY - 30' Home run cable 1
67171M J BOX ASSY, SS W/FM LABEL Analog junction box 1
73732 O-RING 28.24 X 2.62 Inside of upper cup 4
55011 KIT, SINGLE, GROUND ROD Single ground rod kit 1
