Section 4: Electrical Installation

04/10

27

51205 Rev. 2

4.4. INSTALLING ACCESSORIES

Listed below are the standard Aegis Coil Scale Accessories.

Coil Cradle

Intrinsically Safe Controller

Stand-alone Instrument Pillar

Smart Sectional Controller

QMB

4.4.1. Coil Cradle Installation

The Coil Cradle arrives to the site fully assembled.

• The Cradle is made from a Polyurethane cradle affixed to a metal angle iron.

─ Resistant to temperatures up to 180°F.

If products to be weighed have a higher temperature

than 180F

, contact the

Fairbanks Solutions Group with complete application specifications.

─ This fastens directly to the deck of the scale.

• Check the corner welds on all joints carefully to be certain they are secure.
• If any part of the Cradle is damaged, return and replace it.

STEPS:

1. Position the Cradle on the Coil Scale Platform.

2. Insert the bolts from the Cradle through the Platform with the provided lock-

washers.
─ Holes are pre-drilled and tapped.

3. Tighten bolts to 18 to 20 lb/ft.

C A U T I O N

Absolutely

NO ARC WELDING

is to be performed on, or near

this scale while the Load Cells are in place and/or connected.

Disconnected and removed ALL the Load Cells during ANY
welding.
