Fairbanks Aegis Coil Scales - Manual (Page 16)

Section 3: Scale Installation
04/10 16 51205 Rev. 2
3.2.4. Positioning the Scale
Position the Scale with these points in mind:
• Use the proper lifting equipment to position and place the scale.
• The scale is to be placed on a flat, solid, level surface, one that fully supports the
weight of the platform plus a full capacity load.
• The smooth surface must be within 1/8”, and on a level plane, within ¼” across
both the length and width of the platform.
• The four corners of the Platform must rest solidly on the surface, and not rock.
Irregular bumps and foreign material under the Platform can cause an “out-of-
level” condition, which will affect the weight accuracy.
• Platform vibrations may also affect the weighing accuracy. Wherever possible,
locate the platform as far away from heavy, low frequency vibrations as much as
possible.
• Do not load the platform if there is any evidence of damage to the platform or
supporting structure.
• Ease of access is very important. Allow plenty of room for maneuvering a fork lift.
• Reading the Indicator is also important to workers, so place it in a very visible
position.
• When installing the Scale and Indicator in an outdoor location, set it up so the
snow, ice accumulation, rain and other conditions do not affect the platform
operations.
