2 of 2
TIME RPML RPMR RPM MP EGT1 EGT1;*F EGT2;*F
17:06:23 2140 2140 2140 22.5 1354 1292 1375
17:06:24 2140 2140 2140 22.5 1354 1292 1375
17:06:25 2140 2140 2140 22.5 1354 1292 1375
17:06:26 2140 2140 2140 22.5 1354 1292 1375
Note: The data continues to the right and includes all displayed data and any additional data that has a
gauge type and/or screen location defined in the Function Configuration Screen. If the GPS is enabled, it
will also be included in the log.
The first 11 lines are header information. The 12 th line (starting with “TIME”) is label information. A label consists
of a Function followed by the units of measure (i.e., F.FLOW;G/HR). The Function name in the label is the same as
the Function name used in the Function Configuration Screen. All the labels and flight data are comma delimited (a
comma is placed between each item). A carriage return line feed (CR LF) designates the end of a line.
