Appendix 2000 XTC
Appendix
Specifications
System: Dual module: transmitter and galvanic
isolator
Enclosure: Galvanic isolator: plastic DIN
mountable case
Transmitter: aluminum case, panel
mountable, Nema 4X, IEC 60529 and IP
66 rated
Classification: ATEX EEx ib IIC T3 (Europe)
Power Requirements: 24VDC, 10.8 watt max power
consumption (8 watts normal)
Ranges: Specific application determined by user.
See Section 1.2 for example ranges.
Sensor: Thermal conductivity sensor (Microsens
MTCS 2201)
Accuracy: ± 2% of full scale at constant temperature
and pressure, ± 5% over 0–50°C range.
Response Time: 10-90% of signal level in less than 30
seconds
Operating Temperature: 0–50°C
Signal Output: 4–20 mA DC linear
Max Load Impedance: 700 Ohms
Sample System: Brass cell block with stainless steel tubing
and 1/4 inch connectors
Pressure: 2-3 psig min inlet pressure
Teledyne Analytical Instruments 26
