Parts, Gas head assemblies, Gas train components – Fulton Edge ICX or FB-F Vertical Tubeless Boilers (Steam), Gas Fired User Manual
Page 91
82-G 1/01
Parts
Gas Head Assemblies
Part No.
Complete Gas Head Assembly
HP
7-54-1000
Natural Gas
4
7-54-1001
Natural Gas
6
7-54-1002
Natural Gas
10
7-54-1003
Natural Gas
15
7-54-1004
Natural Gas
20
7-54-1005
Natural Gas
30
7-54-1006
Natural Gas
40-50
7-54-1007
Natural Gas
60
7-54-1050
Propane Gas
4
7-54-1051
Propane Gas
6
7-54-1052
Propane Gas
10
7-54-1053
Propane Gas
15
7-54-1054
Propane Gas
20
7-54-1055
Propane Gas
30
7-54-1056
Propane Gas
40-50
7-54-1057
Propane Gas
60
Gas Train Components
Part No.
Description
HP
2-30-113
Main Gas Manual Shut Off Valve
(1)
4-15
2-30-114
Main Gas Manual Shut Off Valve
20
2-30-115
Main Gas Manual Shut Off Valve
30-50
2-30-116
Main Gas Manual Shut Off Valve
60
2-30-104
Main Gas Pressure Regulator
(2)
4-15
2-30-105
Main Gas Pressure Regulator
20
2-30-107
Main Gas Pressure Regulator
30-50
2-30-108
Main Gas Pressure Regulator
60
2-30-301
Main Automatic Gas Valve
(3)
4-15
2-30-302
Main Automatic Gas Valve
20
2-30-303
Main Automatic Gas Valve
30-50
2-40-220
Main Automatic Gas Valve Actuator
w/Proof of Closure
(4)
60-100
2-40-254
Main Automatic Gas Valve Body
(5)
60
2-30-198
Leak Test Valve (
6)
4-100
2-40-533
High/Low Gas Pressure Switch
(7)
60-100
Part No.
Description
HP
2-30-113
Final Manual Shut-off Valve
(8)
4-15
2-30-114
Final Manual Shut-off Valve
20
2-30-115
Final Manual Shut-off Valve
30-50
2-30-116
Final Manual Shut-off Valve
60
2-30-111
Pilot Gas Manual Shut-off Valve
(9)
4-100
2-30-102
Pilot Gas Pressure Regulator
(10)
4-100
2-30-298
Pilot Gas Automatic Shut-off Valve
(11)
4-100
