Specifications – Fulton Edge ICX or FB-F Vertical Tubeless Boilers (Steam), Gas Fired User Manual
Page 16
Specifications
Models ICS/ICX/FB
9.5
10
15
20
25
30
Boiler Connections
N. Steam Outlet 15 PSI
N/A
1.5”
2”
3”
3”
3”
NPT
NPT CL150# CL150#
CL150#
Flange Flange
Flange
N. Steam Outlet 150 PSI
1”
1”
1.25”
1.5”
2”
2”
NPT
NPT
NPT
NPT
NPT
NPT
O. Safety Valve Outlet 15 PSI
IN
N/A
0.75
1
1.5
1.5
1.5
MM
19
32
38
38
38
O. Safety Valve Outlet 150 PSI+
IN
1
1
1
1
1
1
(9.5 HP 100 PSI)
MM
25
25
25
25
25
25
P. Safety Valve Inlet 15 PSI++
IN
N/A
0.75
1
1.25
1.25
1.25
MM
19
25
32
32
32
P. Safety Valve Inlet 150 PSI
IN
0.75
0.75
0.75
0.75
0.75
0.75
(9.5 HP 100 PSI)
MM
19
19
19
19
19
19
Q. Feedwater Inlet
IN
1
1
1
1
1
1
MM
25
25
25
25
25
25
R. Blowdown Outlet
IN
1
1
1
1.25
1.25
1.25
MM
25
25
25
32
32
32
S. Water Column Blowdown
IN
1
1
1
1
1
1
MM
25
25
25
25
25
25
Ratings* (Sea level to 3000 ft.)
Output
1000 BTU/HR
318
335
503
670
838
1005
1000 KCAL/HR
80.1
84.4
127
169
211
253
Steam Output
LB/HR
328
345
518
690
863
1035
KG/HR
149
157
235
313
392
470
Approximate Fuel Consumption at Rated Capacity+++
Natural Gas (ICS)
FT3/HR
398
419
628
837
1047
1256
(9” - 13” w.c. req’d)
M3/HR
11.3
11.9
17.8
23.7
29.7
35.4
Natural Gas (ICX)
FT3/HR
384
403
606
807
1009
1210
(9” - 13” w.c. req’d)
M3/HR
10.8
11.4
17.2
22.9
28.6
34.3
Natural Gas Boiler
IN
1
1
1
1.25
1.25
1.5
Connection Size (Std CSD-1)
MM
25
25
25
32
32
38
Oil Inlet Size
IN
1/4
1/4
1/4
1/4
1/4
1/4
MM
6
6
6
6
6
6
Burner
3450 RPM/60 CY
Motor HP
2850 RPM/50 CY
.75
.75
1.5
1.5
1.5
1.5
Electric Power Requirements - Burner Only (in Amps) ***
120V,60 CY, 1 Phase
9.2
9.2
--
--
--
--
240V, 50/60 CY, 1 Phase
4.6
4.6
8.9
8.9
8.9
8.9
208V, 50/60 CY, 3 Phase
3.1
3.1
4.4
4.4
4.4
4.4
240V, 50/60 CY, 3 Phase
2.8
2.8
4.2
4.2
4.2
4.2
480V, 50/60 CY, 3 Phase
1.4
1.4
2.1
2.1
2.1
2.1
Water Content
U.S. GAL
16
24
39
77
82
170
LITERS
61
91
148
292
311
644
Specifications and Dimensions are approximate. We reserve the right to change specifications and/or dimensions..+ High pressure boilers purchased with low pressure
openings may have larger than specified opening sizes, consult factory for correct opening sizes.++ 50 and 60 HP have two safety valves on low pressure.
+++Consumption based on Natural Gas 1000 BTU/ft.
3
. *All ratings from 0 PSIG and at 212 degrees F. *** Control circuit electrical requirement will vary with the system
voltage, please consult factory. --Consult factory.
