Parts
5-60-100
Instruction Manual, Fuel-Fired
2
0.91
5-60-165
Certification Papers
5-60-164
Boiler Documentation for Export Boilers
Boiler Shell Parts
5-12-004
Furnace Refractory 8" OD x 2" ID (9.5 HP Top)
10
4.55
5-12-005
Furnace Refractory 8" OD x 21/2" ID (4 HP Gas Top - Old Style)
10
4.55
5-12-006
Furnace Refractory 8" OD x 3" ID (9.5 HP Bottom )
10
4.55
5-12-007
Furnace Refractory 10" OD x 3" ID (4-10 HP Top)
18
8.18
5-12-008
Furnace Refractory 10" OD x 31/2" ID (15 HP Top)
18
8.18
5-12-009
Furnace Refractory 10" OD x 5" ID (4-15 HP Bottom)
18
8.18
5-12-010
Furnace Refractory 15" OD x 51/2" ID (20 HP Top)
35
15.91
5-12-011
Furnace Refractory 15" OD x 6" ID (30 HP Top)
35
15.91
5-12-012
Furnace Refractory 15" OD x 7" ID (20 & 30 HP Bottom)
35
15.91
5-12-015
Furnace Refractory 24" OD x 8" ID (40 - 60 HP Top)
125
56.82
5-12-016
Furnace Refractory 24" OD X 10" ID (40- 60 HP Bottom)
125
56.82
5-12-017
Furnace Refractory 30" OD x 91/2" ID (80 HP Top)
225
102.27
2-12-000
Furnace Cement- 2 Ib. can
2
0.91
2-12-001
Furnace Cement - 8 Ib. can
8
3.64
2-12-002
Furnace Cement - 15 Ib. can
15
6.82
5-10-353
Flue Cover Ring - 4 & 6 & 9.5 HP
19
8.64
5-10-354
Flue Cover Ring -10 HP
20
9.09
5-10-355
Flue Cover Ring - 15 HP
20.5
9.32
5-10-357
Flue Cover Ring - 20 HP
21
9.55
5-10-359
Flue Cover Ring - 30 HP
25
11.36
5-10-360
Flue Cover Ring - 40-60 HP
40
18.18
5-12-001
Bottom Cleanout Access Plate with Plug 4-30 HP
10
4.55
5-12-002
Bottom Cleanout Access Plate with Plug 40-60 HP
20
9.09
5-12-003
Square Cleanout Plug (Not for Series E)
15
6.82
2-12-064
Flexitalic (HHG) Extra Heavy High Pressure
0.5
0.23
2-12-088
Blue Max HHG
0.05
0.02
5-10-800
Handhole Welding Patch 4-60 HP
1.1
0.5
2-12-004
Handhole Gasket 4-60 HP
0.05
0.02
2-11-105
HandholeYoke
1.5
0.68
2-11-100
3 x 4 Handhole Cover 4-10 HP (White)
2
0.91
2-11-101
3 x 4 Handhole Cover 15 HP (Red) .
2
0.91
2-11-102
3 x 4 Handhole Cover 20 HP (Green)
2
0.91
2-11-103
3 x 4 Handhole Cover 30 HP (Yellow)
2
0.91
2-11-104
3 x 4 Handhole Cover 40-100 HP (Blue)
2
0.91
4-11-010
10 HP Handhole Assembly (White)
7
3.18
4-11-012
15 HP Handhole Assembly (Red)
7
3.18
4-11-014
20 HP Handhole Assembly (Green)
7
3.18
4-11-016
30 HP Handhole Assembly (Yellow)
7
3.18
4-11-018
40 -60 HP Handhole Assembly (Blue)
7
3.18
2-12-504
Blanket Insulation (Sq. ft.)
0.5
0.23
5-21-300
Steel Jacket 4 HP - No Holes Cut
80
36.36
5-21-301
Steel Jacket 6 HP - No Holes Cut
80
36.36
Approx.
Approx.
Part No.
Description
Net Weight Net Weight
(lbs.)
(kgs.)
67-G 1/01
Replacement Parts Listing (available from authorized Fulton Representative)
