Parts
2-30-118
Air Switch 4-100 HP
0.72
0.33
5-20-019
Burner Plate Gas - 4 HP
1
0.45
5-20-007
Burner Plate Gas - 6 & 10 HP
1
0.45
5-20-055
Burner Plate Gas - 9.5 HP
2
0.91
5-20-013
Burner Plate Gas - 15 & 20 HP
1
0.45
5-20-018
Burner Plate Gas - 30-60 HP
1
0.45
2-11-112
Air Deflector - Gas - 6 & 10 HP
11
5.00
2-11-075
Air Deflector - Gas - 9.5 HP
11
5.00
2-11-113
Air Deflector - Gas -15 HP
11
5.00
7-20-088
Air Deflector - Gas - 20 HP
24
10.91
7-20-090
Air Deflector - Gas - 30 HP
24
10.91
7-20-092
Air Deflector - Gas 40 - 60 HP
45
20.45
2-40-533
Gas Pressure Switch High-Low
3.25
1.48
2-40-211
Gas Pressure Switch - Low
4.9
2.23
2-40-212
Gas Pressure Switch - High
4.8
2.18
2-30-298
1/2" Pilot Gas Valve (4-100 HP)
1.5
0.68
2-30-301
1 " Main Gas Valve - V48A
3.2
1.45
2-30-302
1-1/4 " Main Gas Valve - V48A
4
1.82
2-30-303
1-1/2" Main Gas Valve - V48A
4.5
2.05
2-30-312
1-1/2" Gas Valve V5055A
4
1.82
2-30-313
2" Gas Valve V5055A
9.2
4.18
2-40-249
Gas Valve Body - P.O.C V5055C 1"
5
2.27
2-40-252
Gas Valve Body - P.O.C V5055C 1-1/4"
5.1
2.32
2-40-253
Gas Valve Body - P.O.C V5055C 1-1/2"
4.7
2.14
2-40-254
Gas Valve Body - P.O.C V5055C 2"
9.3
4.23
2-40-214
Actuator for 2", 2-1/2" and 3" Valve Body
13.70
6.23
2-40-220
Actuator for 2", 2-1/2" and 3" Valve Body w/Proof of Closure Switch
12.8
5.82
2-30-400
3/4" Vent Valve - 120V Normally Open
3.2
1.45
2-30-401
1" Vent Valve - 120V Normally Open
4.3
1.95
2-30-402
1-1/4" Vent Valve - 120V Normally Open
4.7
2.14
2-30-305
3/4" Solenoid GasValve
1.8
0.82
2-30-306
1" Solenoid Gas Valve
3.9
1.77
2-30-307
1-1/4'' Solenoid Gas Valve
3.9
1.77
2-30-308
1-1/2" Solenoid Gas Valve
4.4
2.00
2-30-198
1/8" Gas Cock (Pet Cock)
0.25
0.11
2-30-111
1/2" Pilot Gas Cock
0.6
0.27
2-30-112
3/4" Main Gas Cock
1.5
0.68
2-30-113
1" Main Gas Cock
2
0.91
2-30-114
1-1/4 " Main Gas Cock
3
1.36
2-30-115
1-1/2 " Main Gas Cock
4.8
2.18
2-30-116
2" Main Gas Cock
4.8
2.18
2-30-021
1" Lubricated Gas Cock
5
2.27
2-30-022
1-1/4" Lubricated Gas Cock
6.5
2.95
2-30-013
1-1/2" Lubricated Gas Cock
7
3.18
2-30-012
2" Lubricated Gas Cock
10
4.55
Approx.
Approx.
Part No.
Description
Net Weight Net Weight
(lbs.)
(kgs.)
70-G 1/01
