Nova-Tech LMI Series G - SG Metering Pump User Manual
Page 54
48
14
425
Check Valve Assembly, Poly-
mer (Discharge)
61645
1
B6, C6
425
Check Valve Assembly, Poly-
mer (Suction)
61646
1
B6, C6
425
Check Valve Assembly, Slurry
used for pumps built before 1
June 2008, Replaced with PN
69026 (See Note 1 and 4)
60827
2
A7
425
Check Valve Assembly, Slurry,
used for pumps built after 1
June 2008
69026
2
A7
425
Check Valve Assembly, Slurry
61277
2
B7, C7
425
Ball Guide PVC For Spring
(Discharge)
60030134071
1
B6, C6
426
Poppet, PVDF
440090078
1
A6
426
Dowel Pin, 316SS, Not used
after 1 June 2008 (See Note 4)
60820
2
A7
426
Spring Seat, PVC
60440045071
1
B6, C6
427
Ball Guide, 316SS, Used after
1 June 2008
69024
2
A7
428
Pin, Retain, 316SS, Used after
1 June 2008
69025
2
A7
435
Union Nut, 1/2 PVC
4320236038
2
A2, A3, A4,
A6, A7, A8
435
Union Nut, PVC (1”)
4320236058
2
B2, B3, B4,
B6, B7, B8,
C2, C3, C4,
C6, C7, C8
435
Connection (1” NPT Male)
450128116
2
B1, C1
435
Connection (1” BSP Male)
450128016
2
B1, C1
437
Valve Clamp, Steel
040215010
2
B1, B2, B3,
B4, C1, C2,
C3, C4
439
Split Washer (M10) 304 SS
4340009015
6
B1, B2, B3,
B4, C1, C2,
C3, C4
441
Hex Head Screw (M10 x 65
mm) 304 SS
4350035765
2
B1, B2, B3,
B4, C1, C2,
C3, C4
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION
PART
NUMBER
QTY
REFERENCE
CODE
- Items not shown.
