Nova-Tech LMI Series G - SG Metering Pump - Manual (Page 40)

34
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
9 230 Diaphragm Support Ring 60035 1
240 Diaphragm Cap, Part of Item 261 60631 1
250 Set Screw, Dog Pt., M10 x 45 mm, Sin-
gle Diaphragm, Part of Item 261 4350071284 1
260 Diaphragm, Part of Item 261 60618 1
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 3050976120 1
270 Diaphragm Support Nut, Part of Item
261 60632 1
280 Diaphragm Head 210760016 1
290 Hex Head Screw, M8 x 90, Single Dia-
phragm 4350035655 6
300 Flat Washer (M8) 4340005085 6
6.6 SG5 METALLIC LIQUID END - STAINLESS STEEL- NPT
Model:
Liquid End: Material:
SG5_ _ _ _ _ _7_ _ _ _ _ _
Note 1: Diaphragm Assembly (261) can be purchased assembled or items 240, 250, 260, and 270
can be purchased separately.
