Nova-Tech LMI Series G - SG Metering Pump User Manual
Page 35
29
6.4 DRIVE, TOP VIEW
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION
PART
NUMBER
QTY
REFERENCE
CODE
7
10
Drive Housing Assembly (Includes
Items 30, 40, and 448))
60001
1
10
Housing, Stroke Counting (Includes
Items 30, 40, and 448)
60877
1
30
Thrust Bearing, Bronze
60014
1
50
Gear (36/43 SPM), 50 Hz/60 Hz (See
Note 1)
S60011
1
50
Gear (72/86 SPM), 50 Hz/60 Hz (See
Note 1)
S60009
1
50
Gear (103/123 SPM), 50 Hz/60 Hz (See
Note 1)
S60829
1
50
Gear (144/173 SPM), 50 Hz/60 Hz (See
Note 1)
S60007
1
50
Gear (180 SPM), 50 Hz (See Note 1)
S60050
1
100
Sliding Crank
60002
1
101
Spring Pin, 0.125 x 1/2
4010003031
1
110
Eccentric, Steel
60003
1
110
Eccentric, Stroke Counting
60875
1
120
Shoe
60052
1
140
Single Row Bearing
4099994000
1
150
Truarc Retaining Ring
4040107231
1
160
Parker O-ring, Buna N
4080095171
1
170
Stroke Adjustment Screw Assembly
60950
1
171
Stroke Screw, Part of Item 170
H60768
1
172
Bearing Retainer, Part of Item 170
H60757
1
174
Socket Head Screw M4 x 8MM, part of
item 170
41663
4
175
Stroke Scale
2530046062
1
185
Dowel Pin 1/8 x 1-3/8, Part of Item 170
4010021143
1
190
Parker O-ring (2-246), Buna N
4080095371
1
200
Cover
H60767
1
205
Hex Head Screw (M8 x 16 mm)
4350001622
4
210
Oil Seal Clamp, Aluminum
60043
1
220
Truarc Retaining Ring
4040133060
1
- Items not shown.
