Nova-Tech LMI Series G - SG Metering Pump - Manual (Page 36)

30
7 - M12 Lockwasher, 18-8 SS 4340009095 6
- M12 Hex Nut, 304 SS 4350000085 6
310 Ball 5/16, Nylon 60152 1
320 Stroke Locking Knob 60398 1
322 O-Ring, 2-012 Bunan N 4080109091 1
330 Stroke Adjustment Knob 70066 1
331 Flat Washer 1/4”, 18.8 SS 4040005012 1
332 Pan Head Screw #8 x 1-1/2”, 18.8 SS 40722 1
335 Logo Decal (Stroke Knob) 70022 1
448 Tubing Connector (1/4” OD x 1/4” ID) 4020479028 1
- Gear Oil (AGMA 5 EP, ZURN EP95) - 1
Quart Can 4070152010 3
- Items not shown.
Note 1: Worm-Gear-Shaft Assembly includes gear (50) worm (342), spring pin (344), spring (360),
worm shaft coupling (346), and bearing cone (340). Gear (50) and worm (342) sold only as assembly
(343)
Note 2: Part number for 56C motor spring (60264) applies to two-piece worm assembly: worm and
motor coupling piece joined together by a spring pin (344). If worm is previous one-piece design (no
spring pin), the correct 56C motor spring part number is 60059.
