Nova-Tech LMI Series G - SG Metering Pump - Manual (Page 48)

42
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
13 225 Adapter Ring, Aluminum 60165 1
227 Socket Head Screw (M8 x 25 mm), Zinc
PLT 4350003473 6
230 Diaphragm Support Ring 60159 1
240 Diaphragm Cap, Part of Item 261 60641 1
250 Set Screw, Dog Pt., M10 x 70 mm, Sin-
gle Diaphragm, Part of Item 261 4350071334 1
260 Diaphragm, Part of Item 261 60162 1
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 60228 1
270 Diaphragm Support Nut, Part of Item
261 60642 1
280 Diaphragm Head 60180 1
290 Hex Head Screw, M12 x 130, Single
Diaphragm 4350036035 6
300 Flat Washer (M12) 4340055073 6
6.10 SG7 METALLIC LIQUID END - STAINLESS STEEL - NPT
Model:
Liquid End: Material:
SG7_ _ _ _ _ _7_ _ _ _ _ _
