Nova-Tech LMI Series G - SG Metering Pump - Manual (Page 44)

38
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
11 230 Diaphragm Support Ring 60070 1
240 Diaphragm Cap, Part of Item 261 60636 1
250 Set Screw, Dog Pt., M10 x 45 mm, Sin-
gle Diaphragm, Part of Item 261 4350071284 1
260 Diaphragm, Part of Item 261 60624 1
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 3050976320 1
270 Diaphragm Support Nut, Part of Item
261 60637 1
280 Diaphragm Head 210761016 1
290 Hex Head Screw, M8 x 90, Single Dia-
phragm 4350035655 6
300 Flat Washer (M8) 4340005085 6
6.8 SG6 METALLIC LIQUID END - STAINLESS STEEL - NPT
Model:
Liquid End: Material:
SG6_ _ _ _ _ _7_ _ _ _ _ _
Note 1: Diaphragm Assembly (261) can be purchased assembled or items 240, 250, 260, and 270
can be purchased separately.
