Nova-Tech LMI Series G - SG Metering Pump User Manual
Page 52
46
14
420
Seat, 316SS, Used after 1
June 2008
69022
2
A7
420
Seat, 1 inch CA20
61216
2
B8, C8
420
Seat, 5/8 CA20
60855
2
A8
421
Ball, 14mm 316SS, (See Note
1 and 4)
60709
2
A1
421
Ball, 14mm 316SS, Not used
after 1 June 2008, Use PN
CV102314 (See Note 1 and 4)
60709
2
A7
421
Ball, 14mm Ceramic, Double
Ball
4370000140
2
A2
422
Ball, 22mm 316SS, ( See Note
2)
60710
2
A1
422
Ball, 5/8 inch Ceramic
4070015171
2
A2, A3, A4
422
Ball, 5/8 inch PVC
4070170173
2
A2
422
Ball, 7/8 inch Ceramic, Double
Ball
4070015211
2
A2
422
Ball, 5/8 inch CA20
4070014173
2
A2, A8
422
Ball, 5/8 inch 316SS
4070014172
2
A2, A6
422
Ball, 9/16 inch 316SS, Used
after 1 June 2008
CV102314
2
A7
422
Ball, 1 inch 316SS
4070014232
2
B1, B6, B7,
C1, C6, C7
422
Ball, 1 inch Ceramic
4070015231
2
B2, B3, B4,
C2, C3, C4
422
Ball, 1 inch CA20
4070014233
2
B8, C8
423
Seat, Seal, and Ball Set
(See Note 2)
2
A1
423
Seat, Seal, and Ball Set
3050436322
2
B1, C1
423
Seat, Seal, and Ball Set
3050879500
2
A2, A3
423
Seat, Seal, and Ball Set
3050879700
2
A4
423
Seat, Seal, and Ball Set
3050629500
2
B2, B3, C2, C3
423
Seat, Seal, and Ball Set
3050629700
2
B4, C4
423A
Spring Hastelloy, Polymer (Dis-
charge)
800123026
1
A6
423A
Spring Hastelloy, Polymer (Dis-
charge)
60800083026
1
B6, C6
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION
PART
NUMBER
QTY
REFERENCE
CODE
- Items not shown.
