36
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
10 230 Diaphragm Support Ring 60070 1
240 Diaphragm Cap, Part of Item 261 60633 1 A, E, F, G
240 Diaphragm Cap, Part of Item 261 60634 1 B
240 Diaphragm Cap, Part of Item 261 60635 1 C
250 Set Screw, Dog Pt., M10 x 45 mm, Sin-
gle Diaphragm, Part of Item 261 4350071284 1
260 Diaphragm, Part of Item 261 60624 1
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 60151 1 A, E, F, G
261 Diaphragm Assembly, (Replaceable
Design, Consists of Items 240, 250,
260, and 270), See Note 1 3050976090 1 B
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 3050976230 1 C
270 Diaphragm Support Nut, Part of Item
261 60637 1
280 Diaphragm Head, PVC 60130 1 A, E, F, G
280 Diaphragm Head, PP 60883 1 B
280 Diaphragm Head, PVDF 60068 1 C
290 Hex Head Screw, M8 x 90, Single Dia-
phragm 4350035655 6
300 Flat Washer (M8) 4340005085 6
300 Back-up Plate SG5/SG6 60754 1 B
6.7 SG6 PLASTIC LIQUID END
Model:
Liquid End: Material: ReferenceCode:
SG6_ _ _ _ _ _8_ _ _ _ _ _ A (PVC)
SG6_ _ _ _ _ _1_ _ _ _ _ _ B (POLY)
SG6_ _ _ _ _ _2_ _ _ _ _ _ C (PVDF)
Model:
Liquid End: Material: ReferenceCode:
SG6_ _ _ _ _ _ P_ _ _ _ _ E (POLYMER)
SG6_ _ _ _ _ _ L_ _ _ _ _ F (SLURRY)
SG6_ _ _ _ _ _ N_ _ _ _ _G (H
2
SO
4
)
Note 1: Diaphragm Assembly (261) can be purchased assembled or items 240, 250, 260, and 270
can be purchased separately.
