FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
8 230 Diaphragm Support Ring 60035 1
240 Diaphragm Cap, Part of Item 261 60628 1 A, E, F, G
240 Diaphragm Cap, Part of Item 261 60629 1 B
240 Diaphragm Cap, Part of Item 261 60630 1 C
250 Set Screw, Dog Pt., M10 x 45 mm, Sin-
gle Diaphragm, Part of Item 261 4350071284 1 A, B, C, E
260 Diaphragm, Part of Item 261 60618 1
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 60150 1 A, E, F, G
261 Diaphragm Assembly, (Replaceable
Design, Consists of Items 240, 250,
260, and 270), See Note 1 3050976110 1 B
261 Diaphragm Assy, (Replaceable Design,
Consists of Items 240, 250, 260, and
270), See Note 1 3050976130 1 C
270 Diaphragm Support Nut, Part of Item
261 60632 1
280 Diaphragm Head, PVC 60033 1 A, E, F, G
280 Diaphragm Head, PP 60032 1 B
280 Diaphragm Head, PVDF 60031 1 C
290 Hex Head Screw, M8 x 90, Single Dia-
phragm 4350035655 6 A, B, C
290 Hex Head Screw, M8 x 110, Double
Diaphragm 4350001655 6 A, B, C
300 Flat Washer (M8) 4340005085 6
300 Back-up Plate SG5/SG6 60754 1 B
6.5 SG5 PLASTIC LIQUID END
Model:
Liquid End: Material: Reference Code:
SG5_ _ _ _ _ _8_ _ _ _ _ _ A (PVC)
SG5_ _ _ _ _ _1_ _ _ _ _ _ B (POLY)
SG5_ _ _ _ _ _2_ _ _ _ _ _ C (PVDF)
Model:
Liquid End: Material: ReferenceCode:
SG5_ _ _ _ _ _ P_ _ _ _ _ E (POLYMER)
SG5_ _ _ _ _ _ L_ _ _ _ _ F (SLURRY)
SG5_ _ _ _ _ _ N_ _ _ _ _G (H
2
SO
4
)
Note 1: Diaphragm Assembly (261) can be purchased assembled or items 240, 250, 260, and 270
can be purchased separately.
