26
6.3 DRIVE, SIDE VIEW
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QTY REFERENCE
CODE
7 40 Bearing Cup (Timken) 4090116050 1
60 Connecting Rod S60654 1
70 Oil Seal, Buna N 60048 1
80 Oil Seal Clamp, Aluminum 60034 1
90 Slotted Pan Head Screw, M3x10,
304 SS 60294 4
340 Bearing Cone (Timken) (See Note 1) 4090116040 1
342 Worm, 8:1 (See Note 1) S60198 1
342 Worm, 10:1 (See Note 1) S60195 1
342 Worm, 14:1 (See Note 1) S60828 1
342 Worm, 20:1 (See Note 1) S60196 1
342 Worm, 40:1 (See Note 1) S60197 1
- Worm Assembly (43 SPM, 56C, 40:1),
Gear S60011 (See Note 1) 60397 1
- Worm Assembly (36 SPM, IEC 80
Frame, 40:1), Gear S60011 (See Note
1) 60224 1
- Worm Assembly (86 SPM, 56C, 20:1),
Gear S60009 (See Note 1) 60396 1
- Worm Assembly (72 SPM, IEC 80
Frame, 20:1), Gear S60009 (See Note
1) 60223 1
- Worm Assembly (173 SPM, 56C, 10:1),
Gear S60007 (See Note 1) 60395 1
- Worm Assembly (144 SPM, IEC 80
Frame, 10:1), Gear S60007 (See Note
1) 60222 1
- Worm Assembly (180 SPM, IEC 80
Frame, 8:1), Gear S60050 (See Note 1) 60221 1
344 Spring Pin, 0.187 x 1-1/8 STL (See
Note 1) 4010005101 1
346 Worm Shaft Coupling, 56C (See Note
1) 60261 1
346 Worm Shaft Coupling, IEC 71 (See
Note 1) 60260 1
- Items not shown
