Nova-Tech LMI Series G - SG Metering Pump User Manual
Page 53
47
14
424
Ball Guide, 316SS, (See Note
2)
210696016
2
A1
424
Ball Guide, 316SS
2920052016
2
B1, C1
424
Ball Guide, PVDF
60024
2
A2, A3, A4, A8
424
Ball Guide, PVC
60030106071
2
B2, C2, C8
424
Ball Guide, PP
030106070
2
B3, C3
424
Ball Guide, PVDF
60030106078
2
B4, C4, B8
424
Ball Guide, PVDF, Polymer
(Suction)
60024
1
A6
424
Ball Guide, PVC, Spring
Loaded, Polymer (Discharge)
030156071
1
A6
424
Ball Guide, PVC (Polymer Suc-
tion)
60030106071
1
B6, C6, C8
424
Ball Guide, PVC Spring
Loaded, Polymer (Discharge)
60030134071
1
B6, C6
424
Ball Guide, Slurry, 316SS, Not
used after 1 June 2008 (See
Note 1 and 4)
60818
2
A7
424
Body, Slurry, 316SS, Used
after 1 June 2008
69023
2
A7
424
Ball Guide, Slurry, 316SS,
(See Note 1 and 4)
61118
2
B7, C7
424
Double Ball Guide, PVC
210696071
2
A2
425
Check Valve Assembly, 316SS
(See Note 1 and 2)
3050876602
2
A1
425
Check Valve Assembly, 316SS
(See Note 1)
3050583022
2
B1, C1
425
Check Valve Assembly, PVC
(See Note 1)
3050870007
2
A2
425
Check Valve Assembly, PVC
(See Note 1)
3050629007
2
B2, C2
425
Check Valve Assembly, POLY
(See Note 1)
3050870009
2
A3
425
Check Valve Assembly, POLY
(See Note 1)
3050629009
2
B3, C3
425
Check Valve Assembly, PVDF
(See Note 1)
3050870008
2
A4
425
Check Valve Assembly, PVDF
(See Note 1)
3050629008
2
B4, C4
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION
PART
NUMBER
QTY
REFERENCE
CODE
- Items not shown.
