27
7 346 Worm Shaft Coupling, IEC 80 (See
Note 1) 60194 1
360 Spring (56C) (See Note 2) 60264 1
360 Spring (IEC 80) (See Note 2) 60225 1
370 Vent with Dip Stick 70067 1
376 IEC 80 Motor Adapter Ring 60199 1
377 Hex Head Screw, M10 x 25MM Steel
(IEC 80 motor) 4350001732 4
390 Motor (1 hp, 1 ph, 1800 rpm, 115/230,
60 hz, 56C) 4112008010 1
390 Motor (1 hp, 3 ph, 1500 rpm, 220/380,
50 hz, 56C) 4112008315 1
390 Motor ( 1hp, 3 ph, 1800 rpm, 230/460,
60 hz, 56C) 4112008310 1
390 Motor (1 hp, 1750 rpm, 90 VDC, PM-
TEFC-56C) 4112008610 1
390 Motor (1 hp, W/VAR SPD AC Drive) 60297 1
400 Hex Head Screw (3/8-16 x 1) (56C
motor) 4050018119 4
400 Hex Head Screw (M10 x 25 mm) (IEC
80 motor) 4350001732 4
410 Flat Washer (3/8) (56C motor) 4040009012 4
410 Flat Washer (M10) (IEC 80 motor) 4340005152 4
417 Caution, Motor Decal G 60148 1
450 Base 61266 1
460 Hex Head Screw (M8 x 35 mm) 4350035542 4
465 Spring Lock Washer (8 mm) 4340009002 4
470 Hex Nut (M8) 4350000042 4
- Items not shown
Note 1: Worm-Gear-Shaft Assembly includes gear (50) worm (342), spring pin (344), spring (360),
worm shaft coupling (346), and bearing cone (340). Gear (50) and worm (342) sold only as assembly
(343)
Note 2: Part number for 56C motor spring (60264) applies to two-piece worm assembly: worm and
motor coupling piece joined together by a spring pin (344). If worm is previous one-piece design (no
spring pin), the correct 56C motor spring part number is 60059.
