Configuring the Switch
3-108
3
Web – Click Port, Rate Limit, Granularity. Select the required rate limit granularity for
Fast Ethernet and Gigabit Ethernet, and click apply.
Figure 3-63 Rate Limit Granularity Configuration
CLI - This example sets and displays Fast Ethernet and Gigabit Ethernet granularity.
Rate Limit Configuration
Use the rate limit configuration pages to apply rate limiting.
Command Usage
• Input and output rate limit can be enabled or disabled for individual interfaces.
Command Attributes
• Port/Trunk – Displays the port number.
• Rate Limit Status – Enables or disables the rate limit. (Default: Disabled)
• Rate Limit Level – Sets the rate limit level.
Note: Actual rate limit = Rate Limit Level * Granularity
Console(config)#rate-limit fastethernet granularity 512 4-145
Console(config)#rate-limit gigabitethernet granularity 33300 4-145
console#show rate-limit 4-145
Fast ethernet granularity: 512
Gigabit ethernet granularity: 33300
Console#
