CC1200-CC1300XL Concrete Saw Manual
5
Introducing the CC1200 and CC1300XL
CC1200 Components
Figure 1: CC1200 Components
1. Handlebars
2. Instrument Panel
3. Depth Indicator
4. Air Cleaner
5. Front Pointer
6. Engine
7. Blade Guard
8. Flange Guard
9. Fuel Tank
10. Muffler
11. Water Supply
12. Frame
13. Belt Guard
14. Blade Shaft
15. Blade Flange
16. Belt Drive
17. Front Wheels
18. Front Axle
19. Rear Wheels
1
2
3
6
5
4
7
14
19
15
16
17
18
12
11
10
8
9
13
