Page 10
6
CC1300XL Components
Figure 2: CC1300XL Components
1. Handlebars
2. Instrument Panel
3. Air Cleaner
4. Front Pointer
5. Engine
6. Blade Guard
7. Flange Guard
8. Muffler
9. Fuel Tank
10. Water Supply
11. Frame
12. Belt Guard
13. Blade Shaft
14. Belt Drive
15. Front Wheels
16. Rear Wheels
17. Front Axle
1
2
5
4
3
6
10
8
7
9
11
12
19
13
14
16
15
17
