WARNING
!
Placement of explosive objects, flammable objects, liquids and vapors close to
the heater may result in explosion, fire, property damage, serious injury or death.
Do not store or use explosive objects, liquids or vapor in the vicinity of the heater.
VALVE
PS
PRESSURE SWITCH
V
F/N: LLV3EP6
Left Panel
SV Series
4
AVOID EQUIPMENT FAILURE
THIS 10 FT. TUBE IS THE
COMBUSTION CHAMBER.
THIS TUBE MUST BE THE FIRST TUBE
FOLLOWING THE BURNER CONTROL BOX.
! INSTALLER
The combustion chamber utilizes either 409
stainless, titanium alloy or aluminized steel -
depending on the model number of your heater.
Rotate the tube’s welded seam to bottom.
Consult the manual(s) for further details.
SERVICE ACCESS PANEL
IGNITER & FLAME SENSE COMPARTMENT 1. Turn off gas & electricity. 2. Remove cover by lifting top cover upward and outward.
CAUTION: HOT SURFACE. KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.
Clearance to combustibles is defined as the minimum distance that must be maintained between the tube
surface, or reflector, and any combustible items (see Figure 1.1). It also pertains to the distance that must
be maintained from moving objects around the tube heater. Refer to Chart 1.1 to determine the required
distances for your model.
Clearance to Combustibles
F/N: LLTB004 (orange)
Applicable on 150-200 MBH models only
SERVICE ACCESS PANEL
IGNITER & FLAME SENSE COMPARTMENT
1. Turn off gas & electricity.
2. Remove cover by lifting top
cover upward and outward.
CAUTION: HOT SURFACE.
KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.
F/N: LLTB026
Right Panel
(Valve Compartment)
Radiant
Tube
Combustion
Chamber 16” Burner Tube
F/N: LL01 - Clearance Safety Tag
(Affix adjacent to heater’s thermostat).
Exhauster Pump
Assembly
Side View
Power Box
Front View
F/N: LLTB032
F/N: LLTB033
1.0 Safety • Safety Labels and Locations • Clearance to Combustibles
