M
o
de
l
N
um
b
er
G
as T
yp
e
(s
el
ec
t on
e)
BT
U
/h
S
tr
aig
ht
L
eng
th
U
-T
ub
e L
en
gt
h
S
tan
dar
d
W
ei
ght
(lb
s.
)
R
ecom
m
end
ed
M
oun
ting
H
ei
gh
t
C
omb
us
tio
n Chamb
er
R
ad
ia
nt Em
itte
r
Tub
e(
s) (
B
lac
k C
oa
te
d)
R
ad
ia
nt S
ur
fac
e Ar
ea
(sq
. f
t.)
36
” B
af
fle S
ec
tion
s
M
ax
imu
m
V
ent
Len
gth
(f
t.)
SV-20-50 N or LP 50,000 22’-7” 13’-0” 140 9’ to 14’ Alum Alum 20.2 5 25
SV-20-60 N or LP 60,000 22’-7” 13’-0” 140 10’ to 15’ Alum Alum 20.2 5 25
SV-20-75 N or LP 75,000 22’-7” 13’-0” 140 10’ to 15’ Alum Alum 20.2 5 30
SV-30-50 N or LP 50,000 32’-3” **17’-8” 180 10’ to 15’ Alum Alum 30.4 4 20
SV-30-60 N or LP 60,000 32’-3” **17’-8” 180 11’ to 18’ Alum Alum 30.4 4 20
SV-30-75 N or LP 75,000 32’-3” **17’-8” 180 12’ to 20’ Alum Alum 30.4 4 25
SV-30-100 N or LP 100,000 32’-3” **17’-8” 180 13’ to 23’ Alum Alum 30.4 3 30
SV-30-125 N or LP 125,000 32’-3” **17’-8” 180 14’ to 25’ Alum Alum 30.4 5 35
SV-40-50 N or LP 50,000 41’-11” 22’-8” 210 11’ to 18’ Alum Alum 40.5 3 20
SV-40-60 N or LP 60,000 41’-11” 22’-8” 210 11’ to 18’ Alum Alum 40.5 3 20
SV-40-75 N or LP 75,000 41’-11” 22’-8” 210 12’ to 20’ Alum Alum 40.5 3 25
SV-40-100 N or LP 100,000 41’-11” 22’-8” 210 13’ to 23’ Alum Alum 40.5 2 25
SV-40-125 N or LP 125,000 41’-11” 22’-8” 210 14’ to 25’ Alum Alum 40.5 4 30
SV-40-150 N or LP 150,000 41’-11” 22’-8” 210 15’ to 27’ Titan Alum 40.5 4 35
SV-40-175 N or LP 175,000 41’-11” 22’-8” 210 16’ to 30’ Titan Alum 40.5 4 35
SV-50-100 N or LP 100,000 51’-7” **27’-4” 255 15’ to 27’ Alum Alum 50.6 1 25
SV-50-125 N or LP 125,000 51’-7” **27’-4” 255 15’ to 27’ Alum Alum 50.6 3 30
SV-50-150 N or LP 150,000 51’-7” **27’-4” 255 16’ to 30’ Titan Alum 50.6 3 30
SV-50-175 N or LP * 175,000 51’-7” **27’-4” 255 17’ to 35’ Titan Alum 50.6 3 35
SV-50-200 N or LP * 200,000 51’-7” **27’-4” 255 18’ to 40’ Titan Alum 50.6 4 35
SV-60-150 N or LP 150,000 61’-3” 32’-4” 285 17’ to 35’ Titan Alum 60.7 2 25
SV-60-175 N or LP * 175,000 61’-3” 32’-4” 285 17’ to 35’ Titan Alum 60.7 2 30
SV-60-200 N or LP * 200,000 61’-3” 32’-4” 285 18’ to 40’ Titan Alum 60.7 3 30
SV-70-175 N or LP * 175,000 70’-11” **37’-0” 320 19’ to 42’ Titan Alum 70.9 1 25
SV-70-200 N or LP * 200,000 70’-11” **37’-0” 320 19’ to 42’ Titan Alum 70.9 2 30
SV-80-200 N or LP * 200,000 80’-7” 42’-0” 350 20’ to 45’ Titan Alum 80.1 1 25
Specifications
SV Series
10
Chart 2.1 • Specifications
See Figure 2.6 for exhauster assembly dimensions.
* Model requires stainless steel tube clamp (P/N: TP-220) to be located at the seam between the first and second
10 ft. tube sections downstream of the burner control box.
** Model requires 5EA-SUB accessory package when installing in a ‘U’ configuration (P/N: TF1B).
Titan = Black coated titanium stabilized aluminized steel.
Alum = Black coated aluminized treated steel.
2.0 Installation • Specifications
