11

Dim. C

Chart 3.1 •

Recommended Mounting Heights and Coverages

NOTE: This chart is provided as a guideline. Actual conditions may dictate variation for this data.

3.0

Installation

Recommended Mounting Heights and Coverages

Figure 3.3

Mounting Height Dimensions (see Chart 3.1 for measurements)

Dim. A

Dim. B

Dim. C

Dim. A

Note: Dimensions A, B & C are based upon heaters hung at the factory recommended mounting height.

Factory recommended mounting heights are listed as a guideline. If infrared heaters are mounted to low
or to high, they may result in discomfort or lack of heat. Detroit Radiant Products Company generally
recommends observing the recommended mounting heights to optimize comfort conditions. However,
certain applications such as spot heating, freeze protection, outdoor patio heating or very high ceilings
may result in the heaters being mounted outside of the factory recommended mounting heights.

M

o

d

el

BT

U R

an

g

e

R

ecom

m

end

ed

M

oun

ting

H

eig

h

t

(f

t.

)

Co

ver

ag

e A

rea

S

tr

ai

g

h

t C

on

fi

g

.

(L

xW)

Co

ver

ag

e A

rea

U

-T

ub

e C

on

fi

g

.

(L

xW)

D

ist

anc

e B

et

w

ee

n

H

ea

te

rs (

ft

.)

D

im

en

sio

n

A

D

ist

anc

e B

et

w

ee

n

H

ea

te

r R

ow

s (

ft

.)

D

im

en

sio

n

B

M

ax

im

um

D

is

ta

n

ce

B

et

w

ee

n H

ea

te

rs

an

d W

al

l (

ft

.)

D

im

en

sio

n

C

20 ft.

50-65 MBH

10’ - 16’

20’ x 12’

12’ x 12’

10’ - 20’

20’ - 40’

16’

75-100 MBH

12’ - 20’

22’ x 15’

N/A

20’ - 30’

30’ - 50’

18’

30 ft.

50-65 MBH

10’ - 16’

30’ x 14’

17’ x 13’

10’ - 20’

20’ - 40’

17’

75-125 MBH

12’ - 20’

33’ x 18’

18’ x 15’

20’ - 30’

30’ - 50’

20’

40 ft.

50-65 MBH

10’ - 16’

40’ x 16’

22’ x 14’

10’ - 20’

20’ - 40’

20’

75-125 MBH

12’ - 20’

44’ x 21’

23’ x 17’

20’ - 30’

30’ - 50’

20’

150-175 MBH

16’ - 30’

45’ x 26’

24’ x 20’

30’ - 40’

40’ - 60’

25’

50 ft.

100-125 MBH

15’ - 25’

55’ x 24’

28’ x 19’

20’ - 30’

30’ - 50’

25’

150-200 MBH

16’ - 30’

56’ x 30’

29’ x 23’

30’ - 40’

40’ - 60’

25’

60 ft.

125 MBH

16’ - 25’

66’ x 27’

33’ x 21’

20’ - 30’

30’ - 50’

25’

150-200 MBH

17’ - 40’

67’ x 34’

34’ x 26’

30’ - 40’

40’ - 60’

25’

70 ft.

175-200 MBH

17’ - 40’

78’ x 38’

39’ x 29’

30’ - 40’

40’ - 60’

30’

80 ft.

200 MBH

18’ - 45’

89’ x 42’

44’ x 32’

30’ - 40’

40’ - 60’

30’
