MOD 30ML Replacement for MOD 30 Instruments
PRODUCT DESCRIPTION
1.2 EXPLANATION OF CATALOG NUMBERS
The products described in this book have catalog numbers that help identify specific
features. In addition, some products are assigned a serial number which can be used to
track manufacturing data. The general format of the catalog number is described in this
section. Specific product descriptions are provided in the following sections.
The catalog number stamped on the product data plate contains a series of single and
multiple-character codes. These codes provide specific information concerning various
electrical and/or structural options. Certain code combinations are not allowed, and
options and combinations are subject to change. An example of a typical catalog number
is as follows:
Base Number
Unused
Electrical Code
Power
Options
Unused
Sample Catalog No. 1800R Z 10 0 2 0 A
Model/Design Level
1.3 BASIC HARDWARE
1.3.1 1800R With MOD 30 Termination Assembly.
The 1800R with MOD 30 termination assembly, Figure 1-1, is designed specifically for
replacement of installed MOD 30 instruments, or expansion of existing MOD 30
installations. The replacement instrument mounts in a MOD 30 bezel or panel cutout
using a mounting scheme that is essentially identical to that of the MOD 30 instruments.
Two cable connectors which accept the MOD 30 instrument cables are provided at the
back of the replacement instrument.
