MOD 30ML Replacement for MOD 30 Instruments
PRODUCT DESCRIPTION
1.1.2 Related Documents
Instructions on the operation and setup activities performed at the front panel of the
replacement instrument are found in the following document:
• IB-1800R-OPR Operation/Setup, MOD 30ML
Reference information on the data base structure and configuration parameters for the
replacement instrument can be found in the following documents:
• IB-1800R-APP Data Base Reference for MOD 30ML Functions
• IB-23G600 Data Base Reference for System, Logic, I/O and Communication Functions
• IB-23G601 Data Base Reference for Advanced Control Functions
• IB-23G602 Data Base Reference for Algorithms, Sequencers, and Table Functions
• IB-23H141 User’s Guide for Application Builder Software
Reference information on ICN/Link communications for this instrument can be found in the
following documents.
• IB-23A160 ICN Planning
• IB-23C001 ICN Communication Link Instruction Book for 1720N
• IB-23C003 ICN Mini Link Board Instruction Book for 1731N, 1732N
• IB-23C004 ICN Mini Link External Instruction Book for 1733N, 1732N
The following set of books is supplied as a bound set with the Application Builder Software
for the MOD 30ML:
• 98280-418 MOD 30ML Multiloop Controller User’s Guide
(includes binder, tabs, IB-1800R-INS, IB-1800R-OPR, IB-1800R-APP,
IB-23G600, IB-23G601, IB-23G602 and IB-23A160)
3
