BASIC OPERATION
28
4-2 PRINTING ON THE TAPE
4-2-1 PITCH PRINT ON THE TAPE
Printing the following contents on the tape.
Tape size= 9mm Pitch length=15mm
SLD SLD SLD SLD SLD SLD
U1
X18 X19 X1A X1B X1C X1D
COM COM
15mm 15mm 15mm 15mm 15mm 15mm 15mm 15mm 15mm
1. Set “MATERIAL=TAPE” and “SIZE=9mm” in the [PRINTED MATERIAL setting screen].
2. [INPUT screen] appears. Make sure that A is turned on.
Press / key to move the cursor to .
3. Press PITCH to set “PITCH LENGTH.” (See 6-4-1:
PITCH LENGTH) Press / key to set “15.0.”
Press ENTER .
Note: It is also possible to input the value by pressing Ten
key.
4. Press key to move the cursor after .
Input U 1 . Press BLOCK to create a new block.
5. Input S L D , then X .
6. Press SEQ to set “SEQUENCE.”
(See 6-8: SEQUENCE)
Press / key to select “16 SCALE.”
