BASIC OPERATION
25
4. BASIC OPERATION
1. Open the cassette cover and load the consumables to use. (See 3: LOADING THE
CONSUMABLES) Then, close the cassette cover and turn the power on.
2. [PRINTED MATERIAL setting screen] appears.
Press / / / key to set “PRINTED MATERIAL” and
“SIZE.”
Press ENTER , and then [INPUT screen] appears.
Note: When changing the material, press SHIFT Esc (P.MATERIAL).
Then [PRINTED MATERIAL setting screen] appears.
In case of changing the kind of material (“TUBE” to “TAPE” or “TAPE” to
“TUBE”), [PITCH LENGTH setting screen] appears. Input the desired pitch
length and then press ENTER .
When changing the material with pressing SHIFT Esc (P.MATERIAL), the
“CHARACTER SIZE” is automatically changed to “AUTO”.
After turning on again, If any document is remained in
the [INPUT screen], the right screen appears.
Press / key to select “INIT.” or “CONTINUE.”
u /
v
key: Move the cursor between “MATERIAL” and “SIZE”
/ key: “MATERIAL”
wxwxw
Select from “TAPE”, “GENERIC TUBE” , “SHIRNKABLE
TUBE”, “NON PVC TUBE” or “MAX TUBE”
“SIZE”
wHwHwHwywHwHwHw
GENERIC TUBE: Select from “2.5”,“3.2”,”3.6”,”4.2”,”5.2” or ”5.5.”
MAX TUBE: Select from “3.2”,”3.6”,”4.2” or ”5.2.”
SHIRNKABLE TUBE: Select from “2.5”,“3.2”,”3.6”,”4.2”,”5.2” or ”5.5.”
NON PVC TUBE: Select from “3.2”,”3.6”,”4.2” or ”5.2.”
TAPE: Select from “5”,”9” or “12.”
