LOADING THE CONSUMABLES
17
3. Rotate the ink ribbon toward the direction
of the arrow until the black surface
appears. (The color changes in the order
of transparent blue black)
When the surface (black) has appeared,
stop rotating.
2. Replacing the ink ribbon, first remove the ink ribbon from the ribbon case.
1. While pressing “Button B,” take out the
ribbon core (green) from the ribbon
case.
2. Next, while pressing “Button A,” take
out the winding core (black) from the
ribbon case.
Button B
Winding core
(Black)
Button A
The color changes.
Rotation
