BEFORE USE

The meanings of edit marks displayed on the screen are as follows.

(1)

: Represents the [PITCH PRINT MODE] activated. Represents a group of blocks

with same pitch length until next [P] mark. (See 6-4: PITCH PRINT)

(2)

: Represents the block. Up to 100 blocks can be input in an entire document.

(See 6-4: PITCH PRINT)

(3)

: Represents the line feed.

(Printing on tubes) 2.5 to 4.2 : Only 1 line can be set.

5.2 and 5.5 : Up to 2 lines can be set, provided 2mm

character size are used.

(Printing on tapes) Up to 3 lines can be set, provided 12mm tape and 2mm

character size are used.

(4)

: Represents the SEQUENCE is set. (See 6-8: SEQUENCE)

2-6 SELECTING THE SCREEN LANGUAGE

You can select the screen language according to the model type of your machine.

Model type

Language

LM-380A A11 , A11-T

English or Chinese(T) (Traditional Chinese Character)

LM-380A A11-C

English or Chinese(C) (Simplified Chinese Character)

LM-380A BSA

English or Chinese(C) (Simplified Chinese Character)

LM-380A BSB

English or Chinese(T) (Traditional Chinese Character)

LM-380A CE

English or Chinese(C) (Simplified Chinese Character)

[HOW TO SELECT]
1. Turn the power on, while pressing L and G at the same time.

The [LANGUAGE MODE screen] appears after displaying the LETATWIN logotype.

2. Select the language by using / key. And then press ENTER , the power supply

automatically turns off.

3. Turn the power on again, then it starts up with the language selected.

[LANGUAGE MODE screen]

Note: When you change the screen language, all of the internal memory is cleared.

When selecting English, you can neither input nor print Chinese characters.
