Magnum Venus Plastech PATRIOT SSB Commissioning and instruction User Manual
Page 3
SSB_Auto Instructions Issue 05
Page3
PDC reset button - PDC count set button
Recirculation Inject Flush
Resin Gel Alarm unit
Note the PDC Counter above can
only be adjusted when PDC white
button is continuously pressed whilst
pressing each counter button to
select predetermined count number
The Catalyst Bottle mounted at the rear of the machine is fitted with a glass
tube to allow observation of catalyst flow during recirculation. It should be
adjusted to remain visible by tightening in position as shown on LH side
illustration.
The RH side illustration is a typical view of the catalyst flowing down in the
glass tube during recirculation. This flow should be seen for each stroke
(upwards or downwards) during pump movement.
Catalyst
flow
