Appendix b – Magnum Venus Plastech DP-1000 (EPO3) User Manual
Page 32
APPENDIX B
SPRAY NOZZLE LIST
Air-Assisted Spray Nozzle List
Use these lists to choose the best output, pattern width, and back pressure for your application.
Orifice Size
Fan Angle
Part Number
Air Cap Used
(degrees)
0.023
40
30423
08228
0.027
40
30427
08229
0.031
40
30431
08229
0.035
40
30435
08229
0.043
40
30443
08229
0.023
50
30523
08228
0.035
50
30535
08229
0.043
50
30543
08229
0.023
60
30623
08228
0.027
60
30627
08229
0.031
60
30631
08229
Tungsten Carbide Spray Nozzle List
Orifice Size
Fan Angle
Part Number
G.P.M.
(degrees)
500. P.S.I.
Water
0.026
25
2501 C
0.35
0.036
25
2502 C
0.71
0.043
25
2503 C
1.10
0.052
25
2503 C
1.40
0.062
25
2506 C
2.10
0.011
40
400017 C
0.06
0.013
40
400025 C
0.09
0.015
40
400033 C
0.12
0.018
40
400050 C
0.18
0.021
40
400067 C
0.24
0.023
40
400080 C
0.28
0.026
40
4001 C
0.35
0.031
40
40015C
0.53
0.036
40
4002 C
0.71
0.043
40
4003 C
1.10
0.052
40
4004 C
1.40
0.062
40
4006 C
2.01
0.072
40
4008 C
2.80
0.078
40
4010 C
3.50
0.011
50
500017 C
0.06
0.013
50
500025 C
0.09
0.015
50
500033 C
0.12
0.018
50
500050 C
0.18
0.021
50
500067 C
0.24
0.023
50
500080 C
0.28
0.026
50
5001 C
0.35
0.031
50
50015 C
0.53
0.036
50
5002 C
0.71
0.043
50
5003 C
1.10
0.052
50
5004 C
1.40
0.062
50
5006 C
2.10
0.072
50
5008 C
2.80
