Parts drawings – Magnum Venus Plastech Quick Shot User Manual
Page 27
Quick Shot Operations Manual
Rev. 03/2013
Page | 27
Parts Drawings:
QS-FM-PRO-11
Quick Shot Assembly
VPRO-45110-QS
11:1 Pro Pump Assembly – Quick Shot
85690-1
Dual Parallel Ball Valve Assembly
RV-1000-XXX
Relief Valve Assembly
PCP-2000-RV-INT Catalyst Pump Assembly
CJ-2000-4-RSP
Catalyst Jug Assembly
HSA-1000
Suction Wand Assembly
